ARRI AMIRA Advanced Camera Set

The ARRI AMIRA expands ARRI's digital camera offering into ENG and documentary style production. The camera features the look of the ARRI ALEXA sensor and puts it into a lightweight and compact body designed to be ready for production right out of the box. Since the AMIRA’s sensor is the same as that of the ALEXA, you’ll get 14 stops of dynamic range, fantastic skin-tone rendition, a native ISO of 800, and EI range from 160 to 3200.

Note: The AMIRA Premium camera set is sold separately. This is ARRI's Advanced AMIRA camera.

Recording in ProRes formats up to 4:4:4 in HD and 2K modes with frame rates up to 200fps, the AMIRA also includes all the standard frame rates of the ALEXA, in addition to some interlaced frame rates (59.94i and 50i), which are necessary for some broadcast applications. All recording is done to CFast 2.0 cards, which are fast and affordable.

The menu system of the camera mirrors the simplicity and ease of use found in the ALEXA; for ENG operation, a number of assignable buttons and dials cover the camera. White balance, EI, and shutter can all be easily adjusted from the outside of the camera with dials on the operator’s side. Also, the camera features an internal motorized ND filter wheel with 0.6, 1.2, and 2.1 ND filters.

The camera records four channels of 24-bit 48Hz audio and features two XLR 3-pin outputs with mic, line, phantom power, and AES3 support. There is also one XLR 5-pin input with stereo/mono mic inputs, line inputs, and phantom power options. The camera can be fitted with an ENG-style attachable microphone and has a side panel dedicated to audio levels. Levels can be set from the side of the camera or set directly to Auto Level.

The AMIRA is easy to balance on the shoulder with a specialized dovetail system on the top and bottom of the camera, and it is designed to snap into a quick-release tripod adapter plate (such as the VCT-14 from Sony). The back of the camera has an Anton Bauer gold mount on it with P-taps for power output, plus you’ll find 12V Hirose 4-pin connectors to power wireless audio and other accessories, as well as an Arri RS connector.

Additional features of the camera include Wi-Fi remote control capabilities, surround-view look around in the EVF and outputs, continuous white balance modes, and extremely quiet operation noise (-20 db).

Features:

• Same sensor and image quality as the ARRI ALEXA
• Records HD 1080 or 2K
• Dynamic range of more than 14 stops, low noise, beautiful skintone and natural color rendering
• Records Rec 709 or Log C images using ProRes LT, 422, 422HQ or 444 codecs
• Speeds of up to 200 fps
• Single-user ergonomics - perfect shoulder balance
• Build-in ND filters
• High-res OLED eyepiece and fold-away LCD monitor
• Comes with a number of preloaded 3D Lut-based looks
• Rugged and reliable build

NOTE: You can verify current recording media compatibility with ARRI's Supported Recording Media Overview.

ARRI AMIRA Viewfinder MVF-1

The ARRI AMIRA Viewfinder MVF-1 is designed to assist single shooters with numerous configurations. Use it traditionally with the OLED eyepiece or fold open the 3.2” LCD to monitor camera settings or live coverage. It permits playback of recorded footage.

Access important camera controls to minimize delays on set. ARRI has added new peaking functions. You can also use zebra and false color tools or focus via easy-access buttons.

The OLED eyepiece viewfinder delivers optimal performance and color rendition. The eyepiece is mounted to a rugged, lightweight sliding bar so you can alter position to suit your comfort or your needs. Slide it forward and back, as well as side-to-side. Choose which vital camera information will be displayed for you inside the viewfinder.

The fold-away LCD display is daylight visible and ideal for either a single-operator your as a monitor for your director or other crew members. It is bright enough to playback footage in just about any situation. Its full-access to camera functionality – the main access to the camera interface – permits quick changes to settings and configurable user buttons.

Due to ARRI’s foresight in creating an ergonomic design, the monitor can be use without removing from the operator’s shoulder. You can tilt it up and down to adjust to any shooting situation.

ARRI SUP 5.2 Update

Download the free-of-charge update available: ARRI SUP 5.2 to enhance the capabilities of your ARRI AMIRA Camera. Remember that your cameras will benefit from the latest improvements, features, and bug fixes from ARRI. Please be sure to download and install the ARRI SUP 5.2 update.

The Release Notes from ARRI, available on the same page as the download link above, will explain the update process for you and also provide more detailed information regarding the changes highlighted for your convenience below.

IMPORTANT NOTE: ARRI and AbelCine do not recommend installing the new update in the middle of a production.

False Color Mode

False Color to show exposure levels based on monitoring processing or based on Log C.

NOTE: The activation of this is global and will be valid for all monitor outputs, in case you are using a Director’s monitor or other on-set field reference monitor.

Viewfinder Gamma Option

Gamma options Standard (SUP4) and Lifted (SUP5)

User Buttons for Audio Gain Control

User buttons (increase/decrease) to control audio gain of audio channel 1 or audio channels 1+2 simultaneously

NOTE: With channel control set to AUTO, the user buttons are non-functional.

Green Tally for Multicam Mode

Support of green tally command via Telnet or Camera Access Protocol (CAP). This displays a green tally overlay in the viewfinder, on your viewfinder monitor, and on SDI processed outputs.

Microphone Attenuation *

Audio setting to apply an attenuation of 26dB to the microphone inputs. Use this to avoid signal clipping when recording audio in loud environments.

Support of new Recording Media

• SanDisk Extreme PRO CFast 2.0 128GB (SDCFSP-128G-xxxD)
• SanDisk Extreme PRO CFast 2.0 256GB (SDCFSP-256G-xxxD)
• SanDisk Extreme PRO CFast 2.0 512GB (K2.0016648)**

*NOTE: AMIRA only.

**NOTE: SanDisk Extreme Pro CFast 2.0 512GB with a special firmware for ARRI will be available in 2018
