The Core SWX JP-A-FS7 Jetpack for Sony FS7 Gold Mount (3-Stud) offers all the accessory power options you're likely to need, in an extremely compact form factor with a factory-installed Anton/Bauer-style Gold Mount (3-stud) battery plate. The all-aluminum design reduces weight without sacrificing durability, featuring (3) 1/4"-20 mounting points (there is an optional "cheese" backplate offering additional 1/4"-20 and 3/8"-16 female threads; sold separately).
The JetPack features the following power distribution options:
- Power connection to your Sony FS7
- Two powertap outputs (power monitors, lights, etc.)
- One USB output (i.e. Redmote, Tascam DR-05, other USB device)
- One 5v Lemo output (i.e. Zoom, AJA)
- Two 12v regulated Hirose 4-pin outputs (i.e. HDV Cameras, DSLRs)
- One 4-pin XLR power input
- Mounting bracket for mounting the Jetpack directly to the back of the Sony FS7 as an alternative to the XDCA-FS7
NOTE: Camera, batteries, and other accessories sold separately.
What's in the Box
- Core SWX JP-A-FS7 Jetpack for Sony FS7 - Gold Mount (3-Stud)
Specifications
Specifications
Key Highlights
- Power Distribution Box
- For Sony PXW-FS7 Camera
- Gold Mount
Battery Accessories
Accessory Type:
Breakout/Distribution Box - with illuminated master "kill" switch
Battery Plate
Battery Plate Choice:
Gold Mount
Compatibility - Camera
Sony:
Sony PXW-FS7
Connectors
Output Connector/Port:
2 x Hirose 4-pin - 12V, Regulated (for HDV Cameras, DSLRs, etc.)
2 x P-Tap - 11-17V DC, Unregulated
1 x USB - 5V, 1A (for REDMOTE, Tascam DR-05, or other USB device)
1 x LEMO 2-Pin - 5V, 2.5A, 0B Connector (for Zoom, AJA, etc.)
Power
Input Voltage:
11-17V DC
Power Input:
1 x 4-pin XLR - Male
Power Output:
1 x DC - to PXW-FS7 Camera
