Kino Flo Diva-Lite 21 LED DMX Kit Universal with Travel Case

Kino Flo Diva-Lite 21 LED DMX Kit Universal with Travel Case

Kit Includes:

• (1) Diva-Lite 21 LED DMX Center, Universal (FIV-L21XCU)
• (1) Honeycomb Louver, 90° (LVR-SL390-P)
• (1) Kino 41 Lollipop with 16mm Baby Receiver Curve
• (2) Cables
• (1) Diva-Lite LED Clamshell Travel Case (KAS-DL21-C)

Diva-Lite 21 LED DMX

The Diva-Lite 21 LED DMX includes a wireless DMX (Lumen Radio^®), a honeycomb louver, and a center mount point for securing it on your light stand. With a tunable Kelvin range of 2500K-9900K, this light dims without any color shift. You also have the option of either manual dimming or DMX dimming with Auto Terminate. This LED is also flicker-free and includes a quiet operation setting.

The unit universal voltage output is 100-240V AC and 24V DC. The AC power includes an IEC connection. DC power (with an input range of 18-36V DC) connects through a 3-Pin XLR (polarity: Pin1=Ground, Pin2=+18-36V DC, Pin3=not used).

Features:

• Tunable Kelvin (2500K-9900K)
• Dimming without color shift
• Green/Magenta control
• Kino Flo presets and Gels
• Dial in any color through Hue Angle and Saturation control
• RGB control
• Manual and DMX dimming with Auto Terminate
• DMX wireless (Lumen Radio)
• Flicker-free
• Quiet operation
• Center mount

DMX Operation

The Diva-Lite LED DMX operates on three DMX channels (in White mode) using DMX512 (six DMX channels in Color mode).
The first channel operates dimming; the 2nd channel operates Kelvin color temperature control; the 3rd channel operates the Hue.

The Diva-Lite LED DMX includes a built-in Lumen Radio receiver that can be operated from your Lumen Radio transmitter (sold separately) or other compatible third-party wireless device. Use wireless when it does not make sense to run cables to your light.

Dial in Your Color

Diva-Lite LED offers (3) menu options: (1) white + (2) color.

White Menu - Kelvin range from 2700K to 6500K with Dimming, Kelvin, and Green/Magenta control channels

Color Menu - Kelvin range from 2500K to 9900K with Dimming, Kelvin, and Green/Magenta, plus three more: Gel, Hue Angle, and Saturation

You can dial in any color through Hue Angle and Saturation control with the controls on back of the light fixture. In addition, the Hue Angle and Saturation behave similar to a traditional color wheel with white light in the center. The Hue angle determines the color along a 360° range. Saturation determines how much color is applied.

The second color menu provides individual control over: Red, Green, Blue (RGB).

Use the included honeycomb louver to modify your light output. This grid offers 90° with a wide beam spread.

Photometrics

@ 2 feet (0.5 meters) - 508 footcandles (7113 lux)

@ 4 feet (1 meters) - footcandles (2409 lux)

@ 6 feet (1.5 meters) - footcandles (1121 lux)

@ 8 feet (2.0 meters) - footcandles (634 lux)

@ 10 feet (2.5 meters) - footcandles (412 lux)

@ 12 feet (3.0 meters) - footcandles (288 lux)

@ 14 feet (3.5 meters) - footcandles (212 lux)

@ 16 feet (4.0 meters) - footcandles (164 lux)

@ 18 feet (4.5 meters) - footcandles (131 lux)

@ 20 feet (5.0 meters) - footcandles (106 lux)

Mounting

The Diva-Lite 21 LED includes a Center Mount with a ball and socket design and a lock down knob. Simply loosen the knob to reorient your light fixture, then tighten the knob to lock it in its new position.

Use the Baby Receiver (16mm) mount point to position your center Lollipop onto your light stand or rig your LED fixture with your mafer clamp and baby pin. Use the eyelet next to the mount point as a place to secure your safety cable when hanging the light.

Heat Management Design

For Kino Flo, heat management is a critical design element of fixture design. The physical heat or buildup heat within the LED fixture will directly influence the color temperature, lumen performance and life of an LED.

A well-maintained temperature extends the lumen maintenance, color temperature and life of an LED. The Diva-Lite LED's unique design operates coolly. It consumes low energy (1.25A, 120V AC) and is properly ventilated to maintain a stable color temperature.

True Match Color-Correct

As with all Kino Flo products, the Diva-Lite LED has been specially formulated to match the spectral distribution curves of today's HD film and video equipment. The Diva-Lite LED offers a high color rendering index of CRI 95. Even while dimming, the fixture is flicker-free and without color shift.

Honeycomb Louver 90°

Control the spread of your light beam with the included Honeycomb Louver with a 90-degree grid. With minimal light loss, this removeable Louver is lightweight and attached to your light with included Velcro fasteners.

Diva-Lite LED Clamshell Travel Case

The Diva-Lite LED Clamshell Case provides a secure way to transport or store your Diva-Lite LED gear. This hard case holds (1) Diva-Lite 12 LED, (1) louver, and (1) stand (not included).
