Overview
ZEISS CZ.2 2-Lens Zoom Bundle #2 (15-30mm, 70-200mm) PL Mount kit includes:
- ZEISS 15-30mm CZ.2 Compact Zoom T2.9
- ZEISS 70-200mm CZ.2 Compact Zoom T2.9
- 2x ZEISS CZ.2 Transport Case
- ZEISS Transport Case Inlay 15-30
- ZEISS Transport Case Inlay 70-200
- ZEISS Interchangeable Mount Set (IMS) EF (for 15-30mm lens)
- ZEISS Interchangeable Mount Set (IMS) EF (for 70-200mm lens)
ZEISS 15-30mm CZ.2 Compact Zoom T2.9
The ZEISS 15-30mm CZ.2 Compact Zoom T2.9 features exquisite optics in a robust, durable package. This lens delivers great flexibility thanks to interchangeable mounts, allowing it to be used with a wide range of cameras from multiple manufacturers. Additionally, it covers a full-frame image format without vignetting, has consistent aperture, excellent sharpness and contrast, minimal distortion and a look that matches the highest quality cinema primes (including ARRI/ZEISS lenses).
ZEISS Cinema Zoom lenses are precision engineered within the tightest possible tolerances. This guarantees you excellent image quality with low distortion, high resolution and excellent color rendition for sharp, punchy pictures.
- PL Mount (Interchangeable)
- Full-frame coverage (36mm x 24mm)
- Max. aperture: T2.9
- No visible focus shift (breathing) while changing focal length
- No visible ramping
- Round iris for organic look
- Nearly 300° focus rotation
- Calibrated focus scales (imperial)
ZEISS 70-200mm T2.9 CZ.2 Cinema Zoom - Imperial, PL Mount
The ZEISS 70-200mm T2.9 CZ.2 Cinema Zoom - Imperial, PL Mount lens features exquisite optics in a robust, durable package, and covers a full-frame image format without vignetting. Featuring an interchangeable lens mount, this Cinema Zoom offers upgrade flexibility for use with any number of existing or future cine and still cameras, eliminating the need to change lens sets.
ZEISS Cinema Zoom lenses are precision engineered within the tightest possible tolerances. This guarantees excellent image quality with low distortion, high resolution and excellent color rendition for sharp, punchy pictures.
Features:
- Full-frame coverage (36 x 24mm)
- T2.9 max. aperture
- "Sweet spot" effect with Super 35 sensors
- Interchangeable lens mount
- No visible focus shift with change in focal length
- Low distortion
- Flare suppression through T* anti-reflex coating and internal light traps
- Robust, cine-style housing
- No visible breathing
- Calibrated focus scales
- Nearly 300° focus rotation
- Round iris for organic look
- No visible ramping
- Color matched
ZEISS CZ.2 Transport Case
ZEISS CZ.2 Transport Case delivers solid storage and transportation for your CZ.2 lens. Add a custom inlay (sold separately) designed for your particular lens to pad and protect your lens.
This hard case features latches, padlock hasps so you can add your own lock. Also includes a drop-down handle.
ZEISS Transport Case Inlay 15-30
ZEISS Transport Case Inlay 15-30 fits inside your ZEISS CZ.2 Transport Case to protect your ZEISS CZ.2 15-30mm lens. It is a foam inlay cut to fit the shape of that particular lens only.
ZEISS Transport Case Inlay 70-200
ZEISS Transport Case Inlay 70-200 fits inside yourZEISS CZ.2 Transport Case to protect your ZEISS CZ.2 70-200mm lens. It is a foam inlay cut to fit the shape of that particular lens only.
ZEISS Interchangeable Mount Set (IMS) EF for 15-30mm T2.9 CZ.2 Compact Zoom Lens
The ZEISS Interchangeable Mount Set (IMS) EF is a Canon EF Mount conversion set for the ZEISS 15-30mm T2.9 CZ.2 Compact Zoom Lens. This set includes an EF Mount ring, adapter ring with support bracket, Torx screws, (11) color-coded shims, and rear lens cap.
NOTE: Flange focal distance varies with camera type; use included shims to perform appropriate adjustment. T6 torque wrench at 0.4 Nm recommended (included in this kit).
Shim Details (in order of thickness):
- Silver: 0.013mm
- Gold: 0.019mm
- Purple: 0.025mm
- Light Blue: 0.032mm
- Red: 0.038mm
- Blue: 0.051mm
- White: 0.064mm
- Green: 0.076mm
- Orange: 0.102mm
- Light Purple: 0.127mm
- Clear: 0.152mm
ZEISS Interchangeable Mount Set (IMS) EF for 70-200mm T2.9 CZ.2 Compact Zoom Lens
The ZEISS Interchangeable Mount Set (IMS) EF is a Canon EF Mount conversion set for the ZEISS 70-200mm T2.9 CZ.2 Compact Zoom Lens. This set includes an EF Mount ring, adapter ring with support bracket, Torx screws, (11) color-coded shims, and rear lens cap.
NOTE: Flange focal distance varies with camera type; use included shims to perform appropriate adjustment. T6 torque wrench at 0.4 Nm recommended (sold separately).
Shim Details (in order of thickness):
- Silver: 0.013mm
- Gold: 0.019mm
- Purple: 0.025mm
- Light blue: 0.032mm
- Red: 0.038mm
- Blue: 0.051mm
- White: 0.064mm
- Green: 0.076mm
- Orange: 0.102mm
- Light purple: 0.127mm
- Clear: 0.152mm
IMPORTANT NOTE: Some ZEISS lens sets come with alternative mounts for working with various camera systems. In these sets, ZEISS provides instructions, tools, and a lens chart to enable end users to change mounts. While it is possible for end users to change mounts, we strongly recommend that this work be completed at a lens service center. AbelCine and other lens service/repair facilities will be able switch lens mounts and guarantee high performance using their optical test equipment.
What's in the Box
- 11 x Color-Coded Shims
- Torx Screw Kit
- Rear Cap (EF)
- Adapter Ring w/ Support Bracket
- EF Mount
- Rear Cap
- Front Cap
- ZEISS 70-200mm T2.9 CZ.2 Cinema Zoom - Imperial, PL Mount
- ZEISS Torx T6 Torque Wrench
- Limited 1-Year Warranty
- Zeiss Transport Case Inlay 70-200
- Limited 1-Year Warranty
- Zeiss Transport Case Inlay 15-30
- 11 x Color-Coded Shims
- Torx Screw Kit
- Rear Cap (EF)
- Adapter Ring w/ Support Bracket
- EF Mount
- Rear Cap
- Front Cap
- ZEISS 15-30mm CZ.2 Cinema Zoom T2.9 - Imperial, PL Mount
- ZEISS CZ.2 Transport Case
Specifications
Key Highlights
- Save 8% on this 2-lens kit
- 15-30mm + 70-200mm CZ.2 Compact Zooms
- Comes with IMS EF mount sets
- Includes (2) cases with case inlays
- Also features a Torx wrench
Compatibility - Lens
Lens Characteristics
Lens Characteristics
Lens Accessories
Compatibility - Lens
Lens Characteristics
Lens Characteristics
Bags & Cases / Covers
Included Products
- ZEISS Interchangeable Mount Set (IMS) EF for 70-200mm T2.9 CZ.2 Cinema Zoom Lens X 1
- ZEISS 70-200mm CZ.2 Cinema Zoom T2.9 - Imperial, PL Mount X 1
- ZEISS Torx T6 Torque Wrench X 1
- ZEISS Transport Case Inlay 70-200 X 1
- ZEISS Transport Case Inlay 15-30 X 1
- ZEISS Interchangeable Mount Set (IMS) EF for CZ.2 15-30mm T2.9 Zoom X 1
- ZEISS 15-30mm CZ.2 Cinema Zoom T2.9 - Imperial, PL Mount X 1
- ZEISS CZ.2 Transport Case X 2
