Overview
With outstanding optical performance, the Canon CINE-SERVO 15-120mm T2.95-3.95 lens (PL Mount) is HDR compatible, and represents the very latest in Canon’s optical design. It achieves 8K optical performance throughout its entire zoom range, with 8K-compatible chromatic aberration correction and optimized coatings, reducing ghosting and flares inside the lens. As with all Canon Cinema EOS zoom lenses, the CINE-SERVO 15-120mm T2.95-3.95 has a consistent warm-color balance to beautifully render skin tones and textures, reduced focus breathing and an 11-blade iris that produces a creamy natural bokeh.
Features
Outstanding quality, outstanding clarity
Capture your subject in exquisite edge-to-edge detail in combination with Super 35mm or Full Frame Cameras while an 11-blade iris produces beautiful specular highlights with cinematic depth-of-field.
Wide-angle with extra reach
The CINE-SERVO 15-120mm T2.95-3.95 is Canon’s widest CINE-SERVO lens, ideal for live events and creative productions. With a built-in 1.5x Extender, full frame sensor cameras achieve edge-to-edge coverage for large format productions.
Advanced communication and efficiency
The EF mount offers advanced lens communication for precise metadata recording. The PL mount lens supports Cooke /i Technology and ZEISS eXtended Data communication.
Integrate into Virtual Systems
With two 20-pin connectors reserved for zoom and focus control, a third 20-pin connector on the lens’s drive unit provides 16-bit encoded data for positional information and outputs Cooke /i Technology and ZEISS eXtended Data (PL Mount only) for use in virtual studios and VR applications.
Cinema EOS Color Science
All Cinema EOS lenses have Canon’s renowned color science in their DNA and deliver warm, pleasing skin tones with accurate and consistent color from lens center to edge.
Robust, Reliable, and Built to Perform
Remove the drive unit to operate the CINE-SERVO 15-120mm T2.95-3.95 like a traditional cinema lens. With a front diameter of 114mm, the CINE-SERVO 15-120mm T2.95-3.95 can use industry-standard accessories such as matte boxes and follow focus units. The focus ring sports 0.8 and 0.5 pitch gears with clear-to-read markings and engravings.
Specifications:
|
Mount Type | PL Mount |
|
Lens Communication | Cooke /iTechnology, ZEISS eXtended Data |
|
Zoom Ratio | 8X |
|
Focal Length | 15 - 120 mm 22.5 - 180 mm |
|
Maximum Diameter Ratio (T-number) | T4.4 at 22.5 -135 mm/T5.9 at 180 mm |
|
Number of Iris Blades | 11 blades |
| Angle of View | |
| Aspect Ratio 1.78:1 Dimensions 24.6 × 13.8 mm |
78.7°× 49.4°at 15 mm 57.3°× 34.1°at 22.5 mm |
| Aspect Ratio 1.9:1 Dimensions 26.2 × 13.8 mm |
82.3°× 49.4°at 15 mm
|
|
Aspect Ratio 1.5:1 | 77.3°× 56.1°at 22.5 mm 11.4°× 7.6°at 180 mm |
|
Minimum Shooting Distance | 0.85 m / 2.8’ |
| Field of View at Minimum Shooting Distance | |
| 1.78:1 24.6 × 13.8 mm |
93.0 × 52.1 cm at 15 mm
|
| 1.9:1 26.2 × 13.8 mm |
99.0 × 52.1 cm at 15 mm
|
| 1.9:1 38.1 × 20.1 mm |
96.0 × 50.6 cm at 22.5 mm |
| 1.5:1 36 × 24 mm |
90.7 × 60.5 cm at 22.5 mm |
| Dimensions | |
|
Front Diameter | Φ 114 mm |
|
Filter Diameter: Hood/Lens | 127mm/112mm |
|
Drive Unit (Detachable) | 3x Hirose 20-pin: 1x Zoom, 1x Focus, 1x Virtual Lens Data |
|
Outer dimensions (w x h x d) | PL Mount: Approx. 186.7 × 131.7 × 286.9 mm |
|
Weight | Approx. 7.5 lbs./3.40 kg |
What's in the Box
- Dust Cap
- Storage Bag
- Operational Manual: Japanese, English, Chinese
- Lens Cap
- Hood
- Canon CINE-SERVO 15-120mm T2.95-3.9 Zoom Lens with 1.5x Extender (PL Mount)
Specifications
Key Highlights
- 8K, 4K, HDR
- Super 35mm Coverage
- Full Frame Sensor Coverage
- PL Mount
- 11 Iris Blades
- 15-120mm focal length
- Enhanced Servo drive unit (Removable)
- Focus, Zoom, and Iris dials
