Overview
This package includes the following items:
- Ultimate 2575D Fluid Head (C1234-0006)
- Euro Style Quick Release (2575-120)
- Pan Handle (2575-137)
- Pan Handle Extension (2575-135)
- Mitchell Base & Tiedown (08281 & C1234-1018)
- 150mm Ball Base & Tiedown (08414 & C1234-1017)
The OConnor Ultimate 2575D Fluid Head Package - Mitchell & 150mm Base features OConnor’s patented sinusoidal counterbalance system for true, accurate balance at any point in the tilt range. The 2575D also boasts stepless, ultra-smooth pan & tilt fluid drag for ultimate control and stability. While the 2575D retains a large number of functions and capabilities from its predecessors, it also includes many updated features:
- Platform controls on the operator’s side of the head
- Platform release lever with a one touch finger actuated safety release catch, allowing for one “finger” or hand action to disengage the safety catch and open the lever
- Dual platform scales
- Platform with (4) handle rosettes
- Soft hand rest on left hand side
Specifications:
- Capacity:
- @ 4": 133 lb (60.5 kg)
- @ 6": 105 lb (47.7kg)
- @ 8": 87 lb (39.5 kg)
- Platform: 120mm Euro Plate
- Handle(s): 0° & 30°
- Bases: Mitchell, 150mm
- Tilt: +90° / -90°
- Height: 8.4" (21.3 cm)
- Width: 12.4" (31.5 cm)
- Depth: 8.6" (21.8 cm)
- Weight: 22.9 lb (10.4 kg)
What's in the Box
- 150mm Ball Base & Tiedown (08414 & C1234-1017)
- Mitchell Base & Tiedown (08281 & C1234-1018)
- Pan Handle Extension (2575-135)
- Pan Handle (2575-137)
- Euro Style Quick Release (2575-120)
- Ultimate 2575D Fluid Head (C1234-0006)
Specifications
Specifications
Key Highlights
- OConnor 2575D Fluid Head Package
- Up to 90 lb (40.8 kg) max. payload
- Includes Mitchell & 150mm Base w/ TD
- Includes Euro QR Plate
- Includes Pan Handle + Extension
Tripod - Heads Only
Head Max Payload:
Up to 90 lb - 40.8kg
Head Mount Type:
Flat Mitchell Base
150mm Ball
Motorized:
No
Head Tilt Range:
+90° / -90°
Head Type:
Fluid Head
Pan Bar Positions:
4
Panoramic Rotation:
360°
Head Weight:
22.9 lb - 10.4kg
Head Features:
Telescopic Pan Bar - 30° Angle, 11.5" (29.2cm) Extension
Sliding Plate - Sold Separately
Quick Release - Euro Style - 4.7" (120 mm)
Disc Brake System - Tilt caliper brake with independent horizontal center lock; Pan caliper brake
Bubble Level - Illuminated
Tilt Drag - Continuously variable fluid drag
Continuously Variable Dual-Axis Sinusoidal Counterbalance System
